Miller 1737 System Arrow 55/HD


The Arrow 55 Heavy Duty Single Stage tripod system combines the 100mm ball levelling Arrow 55 fluid head with extremely stable HD tripod. The system provides higher load capacity to suit documentary, lifestyle, HD productions and is particularly suited to long-lens applications or Studio/EFP configurations.


We try to have plenty of inventory available to satisfy our customer's needs, however Due to the recent supply chain situation. We suggest you verify by contacting us Availability before placing your order online.


  • Rugged Heavy Duty alloy single stage tripod
  • Adjustable mid-level spreader
  • Patented Split carry handles
  • Arrow55 7-Position selectable Pan and Tilt head
  • 4-position rear-mount Counterbalance
  • Illuminated rear controls



Single Stage

Maximum Height:
1737 mm (68.4 in)
Minimum Height:
947 mm (37.3 in)

Mounting Standard:
100mm ball levelling
Payload Capacity:
25.00 kg (55.1 lbs)

Payload Range:
10-25 kg / 22-55 lbs
Transport Length:
1092 mm (43 in)

9.55 kg (21.1 lbs)

 ** Product Authorized to sell in Latin America Only
