SKU0077

Barix Annuncicom 100

Barix Annuncicom 100

We try to have plenty of inventory available to satisfy our customer's needs, however Due to the recent supply chain situation. We suggest you verify by contacting us Availability before placing your order online.

FUNCTIONALITY

  IP Paging and Intercom codec device with mic/speaker and line level interfaces. 2W output power into 8 Ohm, contact closure inputs and relay output. Useable as paging gateway, small zone device and Intercom device.

APPLICATIONS

  • VHF Radio Controller and interface to IP
  • Microphone Encoder for IP Audio Surveillance
  • Door Intercom Controller, VoIP based
  • Help Point/SOS call box device
  • Classroom VoIP device with built-in amplifier, talkback, serial port
  • Paging and Audio Distribution with Amplifier control and monitoring
  • Generic, bidirectional full-duplex VoIP module for Paging and Intercom Applications
  • Live IP Audio Encoder for Streaming Applications
  • Digital Annunciator, Message Player, Message Repeater
  • SIP and IP Paging Zone Device

FEATURES

  • MP3, G.711, G.722*, PCM Encoding
  • MP3, G.711, G.722*, PCM Decoding
  • Shoutcast/Icecast Source capability
  • Audio Level Supervision with SNMP Trap generation
  • IP Streaming via TCP, UDP, RTP, Multicast
  • Microphone Input
  • Line Level Input
  • Line Level Output
  • Amplified Output 2W (8Ohm)
  • Relay Output (1)
  • Contact Closure Input (2)
  • RS-232 Serial Port (1)
  • RS-485 Serial Port (1)
  • Supply Voltage (16..30VDC)
