Barix Annuncicom 155 Accessory Kit
- Universal power supply 24 VDC 750 mA with M12 connector „A"-type female and four country / region specific interchangeable socket plugs
- Network cable RJ-45 to M12 „D" male connector
- M12 „A" male connector for RS-485 socket
- D-Sub 15 pin connector for Audio & I/O socket
The Annuncicom 155 Accessory Kit content allows for quick bench test installation or presetting / validating the Barix Annuncicom 155 for the use in the field.
Four interchangeable plugs allow for adapting the power supply to the power socket standard of your country, while the attached M12 „A"-type plug ensures a reliable power connection to the Annuncicom 155.
The supplied network cable allows for using a standard switch with RJ-45 sockets while supporting the devices industrial M12 ethernet socket.
The male M12 „A"-type connector can be used for soldering your custom RS-485 cable to test the devices serial port. The included male 15 pin D-Sub connector can be used to solder the audio connections such as microphone and speaker cables as well as the I/O connections (push buttons and LED) to test the audio and the physical user interface.
