With the Airlite MK2 mixer you can now own a modern type of radio mixer for a very attractive price.
It’s a new carefully handmade piece of precision equipment and well built around proven low noise circuitry.
It is an intelligent mixer with an internal USB control section that comfortably enhances daily use and even has a silence detector built in.
It is a reliable workhorse for the self-op production D.J.
It has a built in Telephone VOIP functionality, 4 in/out channels of stereo USB and 3 very low noise Mic inputs.
Mic inputs : bal, 2 kOhm, XLR ,48 volt Phantom.
Noise : - 128 dBr (A-weighted).
Sensitivity : - 70dB min, OdB Max.
Insert : Jack unbal. send 600 Ohm -10dBv.
Aux ret : unbalanced 10kOhm -10dBv.
Line inputs : unbal., 10kOhm, Cinch.
Gain : range of 40dB.
USB : 4x Stereo in and 4x stereo out.
Air input : - 10 dBv at 10kOhm stereo
Aux Ret : - 10 dBv at 10kOhm stereo
Left/Right : + 6dBu bal /XLR. -10dBv/Cinch
CRM/Aux : + 6dBu unbal. on Cinch.
Headphones : 32-400 Ohm, Jack. (TPA 6120)
Announcer : 32-400 Ohm, Jack. (TPA 6120)
USB out : Program/Aux/Voice track/Non Stop
High : + / -12 dB at 12kHz shelving.
Mid : + / -12dB at 1 kHz bell curve.
Low : + / -12dB at 60 Hz bell curve.
Digital AES/EBU main stereo outputs.
The console is prepared to accept an extra pcboard with all the electronics to create a full digital output on the already installed 3 pin XLR.
The AES/EBU option of the Airlite can be configured as a 24 bit 48Khz or 24 bit 96Khz codec with the option of -9dbfs or -20dbfs reference. The codec used is from AsahiKASEI, manufacturer of codecs used in many Pro audio applications.
Left-Right : 482 mm
Front-Back : 365 mm (8HE).
Height : 103 mm.
Front panel thickness : 2 mm
Radius Corners : 20 mm
Weight : 10 kg.
Drop through hole : 449 x 344 mm
