Miller 1741 System Arrow 55/HD ENG-CF

The Arrow 55 Heavy Duty 2 Stage CF tripod system combines the 100mm ball levelling Arrow 55 fluid head with rugged HD tripod. The system provides higher load capacity to suit documentary, lifestyle, HD productions and is particularly suited to long-lens applications or Studio/EFP configurations.


We try to have plenty of inventory available to satisfy our customer's needs, however Due to the recent supply chain situation. We suggest you verify by contacting us Availability before placing your order online.


  • Rugged Heavy Duty 2-stage carbon tripod
  • Adjustable mid-level spreader
  • Patented Split carry handles
  • Arrow 55 7-Position selectable Pan and Tilt head
  • 4-position rear-mount Counterbalance
  • Illuminated rear controls


Carbon Fibre

Maximum Height:
1752 mm (69 in)
Minimum Height:
642 mm (25.3 in)

Mounting Standard:
100mm ball levelling
Payload Capacity:
25.00 kg (55.1 lbs)

Payload Range:
10-25 kg / 22-55 lbs
Transport Length:
912 mm (35.9 in)

12.95 kg (28.5 lbs)

** Product Authorized to sell in Latin America Only
