NTG1

Rode NTG1 - Premium Shotgun Microphone

We try to have plenty of inventory available to satisfy our customer's needs, however Due to the recent supply chain situation. We suggest you verify by contacting us Availability before placing your order online.

Rode NTG1 - Premium Shotgun Microphone

The NTG1 is a lightweight condenser shotgun microphone, designed for professional applications in film, video, television and broadcast. Its full frequency response, low noise and transparency make it ideal in a range of applications, including filmmaking, voice-over and streaming, while its low weight (105 grams) makes it an ideal boom microphone. It also features a switchable high-pass filter for added flexibility.

Key Features:

  • Premium shotgun microphone
  • Low noise and full frequency response
  • Highly directional supercardioid polar pattern
  • High-pass filter (80Hz)
  • Lightweight (105 grams) and easy to use
  • Acoustic & Electrical Specifications

    Acoustic Principle
    Line Gradient

    Active Electronics
    JFET impedance convertor with bipolar output buffer

    Capsule
    0.50"

    Polar Pattern
    Supercardioid

    Address Type
    End

    Frequency Range
    20Hz - 20kHz

    Output Impedance
    50Ω

    Maximum SPL
    139dB SPL

    Maximum Output Level
    6.9mV (@ 1kHz, 1% THD into 1KΩ load)

    Sensitivity
    -36.0dB re 1 Volt/Pascal (15.00mV @ 94 dB SPL) +/- 2 dB @ 1kHz

    Equivalent Noise Level (A-Weighted)
    18dBA

    Power Requirements
    P24 and P48

    Output Connection
    XLR
