SMART CG NET IP


SMART CG NET IP


The SMART CG NET IP HD flexibility allows multiple operations such as:

  • 3 Layers.
  • Insertion of 3D LOGOS with Alpha Channel. Insertion of Time, Temperature and Humidity.
  • ALPHA CHANNEL Trim.
  • Titles and subtitles in real time.
  • Excellent live performance.
  • Multiple layers per page with independent control.
  • Fade In / Fade-Out control.
  • Roll, Crawl, TGA Series and Socket Broadcasting.
  • Project content in one file.
  • More than 200 predefined templates to its immediate use.
  • It Supports PSD, TGA, TIF, GIF, PNG, BMP, EMF, JPG, PCX, JP2, TGA Series, etc.

Generation and insertion of characters in real time, time, temperature and timers on screen; NTSC or PAL; editor in multiple layers; creates, imports and edits BMP, TGA, TIF, JPG, PSD, TGA series, etc.; includes more than 200 templates to different types of programs; supports True Type Fonts; modes of play: automatic or manual; onscreen preview; keyboard/mouse controlled or optional remote control. Allows overprinting to 1 Roll o 1 Crawl o 1 Video with Alpha Channel or TGA Series plus a LOGO (with movement) layer and another one to HTH. Cut by Alpha Channel



Supported HD FORMATS:

720p 24fr, 25 fr, 29fr, 30fr, 50fr, 59fr, 60fr 1080i 50fr, 59fr, 60 fr 1080p 24fr, 25fr, 29fr, 30fr



Supported SD FORMAT: PAL / NTSC



OUTPUT: Graphics & Alpha trough IP - connection via Gigabit Ethernet



HARDWARE REQUIREMENTS: PC with Intel Processor, 430W Power, 3 Hard Disc, PCI Express Video board 1 Gbytes (preferable: Quadro 600), DDR3, DVD, Windows SEVEN, Keyboard and Mouse
