SCV-30001-LB

Overview

1, 2, 3 kVA (Universal Tower / Rack Mount) Single Phase, On-Line Double Conversion, Uninterruptible Power Supply.
The UniStar® V features a field-proven Digital Signal Processor (DSP) achieving high reliability, while providing protection from electrical power disturbances to the connected load. The convertible tower/rack design offers maximum flexibility, enabling UPS integration into a wide variety of environments.
Industry-leading functionality is standard and includes hot swappable battery, powerful internal charger, emergency shut-down and programmable receptacles. The UniStar® V is an ideal power protection solution for servers, networks, telecommunications, industrial equipment, and manufacturing processes.

Features

• Tower/Rack Mount Convertible Design
• Compact and Lightweight
• Advanced Digital Control Technology
• Wide Input Voltage and Frequency Ranges
• Near Unity Power Factor
• Hot Swappable Battery, Built-in Charger
• Optional Extended Run Time Capability
• Optional Make-Before-Break Maintenance Bypass
• DC-start function Programmable receptacles
• Emergency shutdown control
• Communication software
• user-friendly Plug-and-Play design
• Innovative battery management circuit
• Internal maintenance-free sealed-type battery

Specifications

• Load kVA / kW: 3kVA / 2.7kW
• Input Voltage: 120
• Output Voltage: 120
• Input Cord: L5-30P
• Output Connection: (4) 5-15R, (1) L5-30R
• Dimensions W x H x D (inches): 17.2 x 3.5 x 23.6 (2U)
• Weight (lbs): 31
