Auto-Sensing Headset Connector
The MS-4002 has a built-in autosensing headset connector that will determine automatically whether a dynamic or electret headset is connected to the system.
Speaker Station or Headset Station
Use the built-in speaker for listening and add an optional MCP-90 series Gooseneck Panel Microphone for talkback. You can also turn off the speaker volume, and plug in a headset for private communication.
Voice Activated Microphone (VOX)
Separate controls adjust the voice activation level for the headset microphone and panel microphone inputs.
Public Address (PA) Output, with PA key
Use your intercom microphone to talk over a PA system.
Improves visibility in low-light
Incoming Call Indications
Red flashing call light, with beep tone if desired.
Mic Kill Key
You can turn off all microphones on a channel to quickly clear the channel.
Program Input for Each Channel
Connect any line-level audio source for monitoring in the speaker or headset, or for routing to the intercom channel. The program audio to the channel can be set to interrupt while the MS-4002 operator is talking on the channel.
Listening with External Powered Speakers
You can connect external powered speakers and then monitor channels 1, 2, 3 and 4.
Add more channels by connecting optional EMS-4001 Expansion Stations. Each EMS-4001 adds four additional powered channels (up to twenty channels).
Instantaneous Auto Reset (IAR), the newest technology in performance and safety, which uses a revolutionary new circuitry that dynamically monitors line fault conditions. Then, when the fault is removed, automatically brings individual power supply channels up.
10.31" (261.9 mm)
1.75" (44.5 mm)
|Power Requirements |
AC Input: 100-240 VAC, 50/60 Hz, Channel Power: 24 VDC nominal (12 to 30 VDC), 65 to 150 mA MS-4002 is capable of supplying 4 amps overall
4.41 lbs (2 kg)
19" (482.6 mm)
Can run in unbalanced mode.
** Product Authorized to sell in Latin America Only
