VIDEO 5 Smarts Server Channel in a Box DH

We try to have plenty of inventory available to satisfy our customer's needs, however Due to the recent supply chain situation. We suggest you verify by contacting us Availability before placing your order online.



BROADCAST Video Server with three graphics layers , ideal for automation or live work for television that incorporates a set of cuttingedge technologies, allowing full control of different types of multiformat content .


The flexibility of SMART SERVER allows multiple operations:


Simultaneous Recording and Playback, Real-Time Compression, Broadcast Quality, 3 graphics layers with Alpha Channel cut, broadcast content in a single Multi Play List, Define multiple clips on the same video, schedule, Air Control, Defining Metadata for each video file in Header or database integration, emission reports and trade certification viewing, frame by frame search , possibility to define multiple clips on the same video, SQL databases, pre view onscreen , Video Trim.


3 graphics layers: Inserting Logo, Inserting Time Temperature and Humidity, and emossion of roll or crawl or video with Alpha Channel or TGA series or lower thirds.


Supports AVI, MOV and MPG

Multiple selectable compression formats 1080P, 1080i, 720p, Frames 23.98/24/48/50/59.94/60, MPEG 2 (ISO / IEC 13818-2) (VBR, CBR) up to 80 Mbps, WMV HD, DVCPRO HD.


Video Input: SDI 2xSD/HD

Video output: SDI 2xSD/HD


Audio Input: 16 Channels Per Input, Embedded in SD and HD.

Audio Output: 16 Channels, Embedded in SD and HD.


Genlock: SDI or Tri_level


INCLUDES: Computer with INTEL processor, 12 GB of RAM Total, 430W Power, HD HDX500 and 3 HDx1 TBytes on RAID 0, PCI Express Video Card 1 GB DDR3, DVD, 4U Cabinets on RACK, Keyboard, Mouse, Windows SEVEN Professional License.
