Yellowtec YT2305 AoIP Module

We try to have plenty of inventory available to satisfy our customer's needs, however Due to the recent supply chain situation. We suggest you verify by contacting us Availability before placing your order online.

The optional X64 AoIP Extension for your Intellimix Focus or Intellimix II Desktop Mixer (producted until 2019) gets you enhanced AoIP conenctivity. With X64 you get 64-channel AES67 in and outs (8 streams), nDNS / SDP / RAVENNA Advertisement, Livewire Advertisement GPIO Control, SAP / Dante Advertisement and NMOS Advertisement. On top, it makes your Intellimix SMPTE ST2110 ready.

The X64 AoIP Extension is integrated into your Intellimix Focus Base Unit. The Intellimix Base Unit is where the audio-processing takes place. Headphone and microphone inputs are directly accessible on its front side. All the other in- and outputs are located on the Base Unit's rear side. This is also the spot to access X64 AoIP.

The internal X64 AoIP Extension needs to be installed by Yellowtec. Please add the extension when ordering a new Intellimix Focus or contact us to send in your current Intellimix Focus Base Unit to upgrade to X64 AoIP.


  • Internal AoIP extension for Intellimix Focus / Intellimix II (until 2019)
  • Not designed for Intellimix Pro as it comes with integrated X64 as standard
  • Needs to be installed in the Intellimix Base Unit by Yellowtec
  • AES67 64-Kanal In 64-Kanal Out (8 Streams)
  • nDNS / SDP / RAVENNA Advertisement
  • Livewire Advertisement GPIO Control
  • SAP / Dante Advertisement
  • NMOS Advertisement
  • SMPTE ST2110 ready
